RSRV®
With three unique wood patterns sharing six common base colors, RSRV® provides a variety of registered embossed plank styles to mix and match, along with four concrete patterned tiles. Specify from wood grain looks that include the fine lines and bold size of “Kyoto” at 9.25” x 71.45” x 6.0mm, or the rugged aged look of “Komma” or the pure grains of “Washed” in a 6.6” x 59.75” x 6.0mm. All RSRV® concrete patterned tiles are formatted in the popular 18” x 36” nominal x 6.0mm.
The entire RSRV® collection by AVA® features a hefty 22 mil wear layer plus our patented AMP Advantage coating: a high-strength, diamond-like wear-resistance with particles that exceed the hardness of tungsten and aluminum oxide. The result is 30% more scratch-resistance over typical coatings.
The robust style, High Density Core (HDC) clic construction and IXPE acoustical backing makes RSRV® a perfect selection for busy Hospitality and Retail locations where style, comfort and performance are always in demand.
| SPECIFICATIONS: | |
|---|---|
| ASTM F1700-13 SOLID VINYL FLOOR TILE: | CLASS III, TYPE B |
| ASTM D2047 STATIC COF FOR POLISHED SURFACES: | EXCEEDS INDUSTRY STANDARDS |
| ASTM F970-07 STATIC LOAD LIMIT: | PASSES (MODIFIED EXCEEDS 1000 LBS PSI) |
| ASTM E648 CRITICAL RADIANT FLUX: | CLASS 1 |
| ASTM E662 SMOKE DENSITY: | PASSES |
| ASTM F925 STAIN & CHEMICAL RESISTANCE: | EXCELLENT |
| WEAR LAYER: | 22 MIL |
| OVERALL THICKNESS: | 6.0 MM |
| KYOTO SIZE: | 9.25″ X 71.45″ |
| KOMMA & WASHED SIZE: | 6.6″ X 60″ |
| TILE SIZE: | 18” X 36” NOMINAL |
| WARRANTY: | LIFETIME RESIDENTIAL, 15 YEAR LIGHT COMMERCIAL |
| 100% PHTHALATE FREE | REACH COMPLIANT |
| ASTM E492 IMPACT INSULATION CLASS: | IIC 54*, 56◊, 53¥, 70§ |
| ASTM E90 AIRBORNE SOUND TRANSMISSION: | STC 51*, 54◊, 60¥, 62§ |
| ASTM E2179 DELTA IMPACT INSULATION CLASS: | ∆IIC 23* |
| * 6″ concrete | ◊ 8 in. Concrete | ¥ 14″ OWT w/ soundmat | § 6″ concrete, gypsum ceiling |
RKY001S-605 – Kyoto Loft
9.25” X 71.45’’
RKY002S-605 – Kyoto Honey
9.25” X 71.45”
RKY003S-605 – Kyoto Cellar
9.25” X 71.45’’
RKY004S-605 – Kyoto Edgewater
9.25” X 71.45”
RKY005S-605 – Kyoto Legacy
9.25” X 71.45”
RKY006S-605 – Kyoto Wharf
9.25” X 71.45”
RKO001S-605 – Komma Loft
6.6” X 59.75”
RKO002S-605 – Komma Honey
6.6” X 59.75”
RKO003S-605 – Komma Cellar
6.6” X 59.75”
RKO004S-605 – Komma Edgewater
6.6” X 59.75”
RKO005S-605 – Komma Legacy
6.6” X 59.75”
RKO006S-605 – Komma Wharf
6.6” X 59.75”
RWA001S-605 – Washed Loft
6.6” X 59.75”
RWA002S-605 – Washed Honey
6.6” X 59.75”
RWA003S-605 – Washed Cellar
6.6” X 59.75”
RWA004S-605 – Washed Edgewater
6.6” X 59.75”
RWA005S-605 – Washed Legacy
6.6” X 59.75”
RWA006S-605 – Washed Wharf
6.6” X 59.75”
RBE001S-605 – Beton Pearl
18” x 36” Nominal
RBE002S-605 -Beton Iron
18” x 36” Nominal
RBE003S-605 – Beton Steel
18” x 36” Nominal
RBE004S-605 – Beton Harbor
18” x 36” Nominal
Color reproduction may vary with your computer or mobile device. For accurate color, please refer to actual product samples in our AVA architect folders or request samples from us.
All AVA® DSGN® patterns are available in glue down, loose lay and Angle/Angle Clic installation systems. Many AVA® DSGN® patterns in all three installation systems are readily available through our USA quick ship program.
Glue Down: the perfect long term flooring solution for heavy traffic areas including areas with heavy rolling loads. With a variety of applications, the glue down system is used in virtually all commercial sectors.
Loose Lay: simple and easy to install, removable and replaceable, the loose lay construction is the flooring choice for raised access applications as well as fast track and temporary installations.
Angle/Angle Clic Instalation is the latest generation of mechanically locked together vinyl floating flooring. The Angle/Angle Clic system is a simple yet secure fold down locking system. Soft underfoot, less permanent than glue down but a more fixed installation than loose lay, Angle/Angle Clic is the ideal flooring system for many applications.
| SPECIFICATIONS: | |
|---|---|
| ASTM F1700-13 SOLID VINYL FLOOR TILE: | CLASS III, TYPE B |
| ASTM D2047 STATIC COF FOR POLISHED SURFACES: | EXCEEDS INDUSTRY STANDARDS |
| ASTM F970-07 STATIC LOAD LIMIT: | PASSES (MODIFIED EXCEEDS 1000 LBS PSI) |
| ASTM E648 CRITICAL RADIANT FLUX: | CLASS 1 |
| ASTM E662 SMOKE DENSITY: | PASSES |
| ASTM F925 STAIN & CHEMICAL RESISTANCE: | EXCELLENT |
| WEAR LAYER: | 20 MIL |
| OVERALL THICKNESS GLUE DOWN: | 2.5 MM |
| OVERALL THICKNESS LOOSE LAY: | 5.0 MM |
| OVERALL THICKNESS 5G CLIC: | 5.0 MM |
| WOOD SIZE GLUE DOWN: | 6” X 48” |
| WOOD SIZE LOOSE LAY: | 9” X 48” |
| WOOD SIZE 5G CLIC: | 7” X 48” |
| STONE SIZE GLUE DOWN: | 12” X 24” |
| STONE SIZE LOOSE LAY: | 18” X 36” |
| STONE SIZE 5G CLIC: | 12” X 24” |
| WARRANTY: | 10 YEAR COMMERCIAL WARRANTY |
| 100% PHTHALATE FREE | REACH COMPLIANT |
