MRGETM
The AVA® MRGE™ collection features four distressed concrete colorways and four modern concrete colorways, plus 10 delicately blended organic styles in earth tone colorways for a total of 18 styles.
MRGE’s 2.5mm 22mil wear layer construction provides superior performance in the toughest commercial settings. The highly durable patented AMP Advantage coating – which provides 30% more scratch resistance over typical coatings – makes MRGE suitable for most any high-traffic commercial application, including Hospitality, Corporate and Retail.
| SPECIFICATIONS: | |
|---|---|
| ASTM F1700-13 SOLID VINYL FLOOR TILE: | CLASS III, TYPE B |
| ASTM F137 FLEXIBILITY: | PASSES, 25.4MM MANDREL |
| ASTM F1914 RESIDUAL INDENTATION: | PASSES, <10% |
| ASTM F2199 DIMENSIONAL STABILITY: | PASSES, <0.020 IN. PER LIN. FT. |
| ASTM F925 CHEMICAL RESISTANCE: | PASSES (ASK FOR CHART) |
| WEAR LAYER: | 22 MIL (0.55 MM) |
| OVERALL THICKNESS: | 2.5 MM |
| ASTM F1514 HEAT COLOR STABILITY: | PASSES, < Δ8E |
| SIZE: | 9.84″ X 39.37″ (PLANKS), 39.37″ X 39.37″ (TILE) |
| ASTM F1515 LIGHT COLOR STABILITY: | PASSES, < Δ8E |
| WARRANTY: | 20 YEAR HEAVY COMMERCIAL | LIFETIME RESIDENTIAL |
| 100% PHTHALATE FREE | REACH COMPLIANT |
| ASTM F970 STATIC LOAD LIMIT: | PASSES, 250 LBS. |
| ASTM F970 MODIFIED FOR MAX WEIGHT: | 1,200 LBS. |
| ASTM E648 (NFPA 253) CRITICAL RADIANT FLUX: | CLASS I, >0.45 W/CM2 |
| ASTM E662 (NFPA 258) SMOKE DENSITY: | PASSES, <450 |
| ASTM D2047 SLIP RESISTANCE: | ASTM D2047 SLIP RESISTANCE: >0.6 (DRY) |
DI001 – Erie
9.84″ X 39.37″
DI002 – Superior
9.84″ X 39.37″
DI003 – Huron
9.84″ X 39.37″
DI004 – Ontario
9.84″ X 39.37″
SN001 – Fossil
9.84″ X 39.37″
SN002 – Bark
9.84″ X 39.37″
SN003 – Dune
9.84″ X 39.37″
SN004 – Dove
9.84″ X 39.37″
SN005 – Cloud
9.84″ X 39.37″
SN006 – Flint
9.84″ X 39.37″
SN007- Slate
9.84″ X 39.37″
SN008 – Onyx
9.84″ X 39.37″
SN009 – Seashell
9.84″ X 39.37″
SN010 – Haze
9.84″ X 39.37″
BN001 – Beton Pearl
39.37″ x 39.37″
BN002 – Beton Iron
39.37″ x 39.37″
BN003 – Beton Steel
39.37″ x 39.37″
BN004 – Beton Harbor
39.37″ x 39.37″
Color reproduction may vary with your computer or mobile device. For accurate color, please refer to actual product samples in our AVA architect folders or request samples from us.
With 24 trendy woods and 8 unique stone designs, the AVA® DSGN® collection is created with the corporate, retail and hospitality sectors in mind.
CLICK TO ENLARGE
Color reproduction may vary with your computer or mobile device. For accurate color, please refer to actual product samples in our AVA architect folders or request samples from us.
All AVA® DSGN® patterns are available in glue down, loose lay and Angle/Angle Clic installation systems. Many AVA® DSGN® patterns in all three installation systems are readily available through our USA quick ship program.
Glue Down: the perfect long term flooring solution for heavy traffic areas including areas with heavy rolling loads. With a variety of applications, the glue down system is used in virtually all commercial sectors.
Loose Lay: simple and easy to install, removable and replaceable, the loose lay construction is the flooring choice for raised access applications as well as fast track and temporary installations.
Angle/Angle Clic Instalation is the latest generation of mechanically locked together vinyl floating flooring. The Angle/Angle Clic system is a simple yet secure fold down locking system. Soft underfoot, less permanent than glue down but a more fixed installation than loose lay, Angle/Angle Clic is the ideal flooring system for many applications.
CLICK TO ENLARGE
| SPECIFICATIONS: | |
|---|---|
| ASTM F1700-13 SOLID VINYL FLOOR TILE: | CLASS III, TYPE B |
| ASTM D2047 STATIC COF FOR POLISHED SURFACES: | EXCEEDS INDUSTRY STANDARDS |
| ASTM F970-07 STATIC LOAD LIMIT: | PASSES (MODIFIED EXCEEDS 1000 LBS PSI) |
| ASTM E648 CRITICAL RADIANT FLUX: | CLASS 1 |
| ASTM E662 SMOKE DENSITY: | PASSES |
| ASTM F925 STAIN & CHEMICAL RESISTANCE: | EXCELLENT |
| WEAR LAYER: | 20 MIL |
| OVERALL THICKNESS GLUE DOWN: | 2.5 MM |
| OVERALL THICKNESS LOOSE LAY: | 5.0 MM |
| OVERALL THICKNESS 5G CLIC: | 5.0 MM |
| WOOD SIZE GLUE DOWN: | 6” X 48” |
| WOOD SIZE LOOSE LAY: | 9” X 48” |
| WOOD SIZE 5G CLIC: | 7” X 48” |
| STONE SIZE GLUE DOWN: | 12” X 24” |
| STONE SIZE LOOSE LAY: | 18” X 36” |
| STONE SIZE 5G CLIC: | 12” X 24” |
| WARRANTY: | 10 YEAR COMMERCIAL WARRANTY |
| 100% PHTHALATE FREE | REACH COMPLIANT |
